Product Name: Precision Engineering & Manufacturing for AR/XR Smart Eyewear | QQS

Project Items: AR Smart Eyewear

Production Introduction: High-precision OEM/ODM manufacturing for AR smart glasses. Specializing in 0.005mm tolerance tooling, Micro-OLED integration, and complex overmolding for lightweight wearable technology.

Mold steel: S136/H13

Mold Base:LKM/HASCO/DME

Surface treatment: printing, polishing

Runner: Hot runner (Yudo, Moldmasters, Husky, Hasco, Synventive, etc.)

Shaping mode: Plastic Injection Molding

Mold lifetime: 100,000~1,000,000 shots

Production lead time:2~5 weeks, according to order qty

Mold payment terms: 50% deposit by T/T against PO, balance by T/T after approval of samples but before shipment

Products payment terms: 30% deposit by T/T against PO, balance by T/T before shipment

Port of loading: Xiamen or other China port, as per customers' requirements

Advanced AR Smart Display Platform: High-Precision Tooling & Integrated Assembly

At XIAMEN QIQIANGSHENG, we bridge the gap between complex optical design and scalable mass production. Our AR Smart Display platform is a testament to our high-precision capabilities, integrating Micro-OLED technology and Birdbath optics into a high-performance, 72g wearable architecture.

For global brand partners, we provide more than just manufacturing; we offer Technical Life-Cycle Support, utilizing Swiss-standard machining to ensure that the "heart" of your smart eyewear—the optics and electronics—is housed in a perfectly engineered frame.

Technical Manufacturing Specifications:

1. Ultra-Precision Optical Housing

• Tooling Precision: All critical optical components are machined using our GF Mikron MILL P 900, achieving tolerances within 0.005mm.

• Alignment Accuracy: We ensure perfect optical axis alignment for Birdbath modules, essential for a clear 120-inch virtual screen experience and user comfort.

2. Advanced Material Science & Structural Design

• Ultra-Thin Wall Molding: Specialized injection techniques allow us to achieve a lightweight 72g footprint while maintaining the structural rigidity required for daily use.

• Ergonomic Overmolding: We utilize multi-shot molding (2K) to combine skin-friendly medical-grade materials with high-strength structural polymers for the temples and nose pads.

3. Vertical PCBA & SMT Integration

• Compact Integration: Our in-house SMT lines are optimized for the high-density PCBA required for Micro-OLED drivers and Type-C DP Alt Mode connectivity.

• Thermal Management: Integrated heat-dissipation structures within the frame ensure stable performance during extended 2D/3D cinema viewing.

4. Mechanical Diopter System

• Precision Adjustment: The integrated 0D to -6D diopter system is engineered with precise torque control, ensuring smooth adjustment and long-term mechanical durability for nearsighted users.

Our ODM/OEM Capability Suite:

• Custom Tooling Development: Rapid DFM (Design for Manufacturing) evaluation to optimize your unique ID (Industrial Design) for mass production.

• Material Customization: Expertise in TR90, PEEK, and specialized optical resins.

• Global Compliance: Full support for CE, FCC, and RoHS certification testing to ensure your product is ready for European and North American markets.

• Strategic Joint Ventures: For disruptive "Urgent Need" technologies, QQS offers unique Asset-for-Equity models, providing our high-precision tooling as a capital investment in your success.

Manufacturing Overview:

• Facility: ISO 9001 Certified.

• Machinery: GF Mikron CNC, High-Speed EDM, Automated SMT Lines.

• Quality Control: 2D/3D Coordinate Measuring (CMM) and Optical Spectrum Analysis.

Q: For this project, what items are provided by QQS?

A: We make the molds, produce the plastic casing, outsource the spare parts, with in-house SMT &  assembly lines, we can provide assembled products for customers. In a word, we provide one-stop services for customers.

Q: What kind of surfaces can you provide?

A: Printing, lase engraving, hot stamping, etc..

Q: Do you have injection machine to produce the parts?

A: Yes, we have our own injection shop, so we can make the production & assembling for customers, if request.

Q: What kind of molds are you making?

A: We mainly make plastic injection molds, but we can also build compression molds (for UF or SMC material) & die casting molds.

Q: How long does it take to build a mold?

A:It varies a little depending on the product sizes and complexity of part, generally speaking, a medium size mold can be finished for T1 within 25~30 days.

Q: How do you handle project tracking and communication for overseas clients?

A:We provide weekly progress reports with high-resolution photos/videos. This is exactly what overseas sourcing managers look for to save travel costs.

Q: How do you guarantee the quality?

A: We will appoint a project manager to follow your molds, who is responsible for every process. Besides that, we have QC for every procedure, and we will also have CMM & online inspection system to guarantee all components stay within tolerance.

Q: Do you support OEM ?

A:Yes, we can produce by technical drawings or samples.

Q: What kind of resin do you proceed with?

A:We process both thermoplastic and thermoset materials..
